Adopt intelligent control system. Temperature can be set as needed. Automatically extinguish when higher than the set temperature,and automatically ignition when belower than the set temperature(factory settings is 30℃).
The whole machine is insulated with insulation cotton,low heat loss,high drying efficiency.
Equipped with high temperature blower, vapor chimney, Accelerate hot airflow, discharge the water vapor,ensure drying effect. Simple and convenient operation, digital display temperature monitoring.
Helical roller driving: Smooth drive, and wide use, suitable for first and multiple burns.
Chain conveyor: Simple structure and easy maintenance, suitable for secondary and multiple burns.
Burner with adjustable ventilation door structure and gas regulating valve,ensures that the combustion is completely premixed with air, direct heating can reach 150-150 ℃.
The burner releases heat by the burning of gas (coal gas, petroleum gas) and infrared radiation, heat conduction and convection.It has the advantages of high heat, quick drying, energy saving and no pollution.
Uniform heating effect, save energy consumption, the drying component can be used according to different usage conditions.
Commonly used after the inkjet or screen printing, suitable for drying the printing glaze or inkjet polished glaze.
Technical Parameter
Model | Dimensions | Inlet width | Brick width | Air consumption | weight | Installation length |
（mm） | （mm） | （mm） | （m³/h） | （kg） | （mm） |
HG-R700/4 | 2470X835X1150 | 700 | 300-500 | 2 | 400 | 2100 |
HG-R900/4 | 2470X1035X1150 | 900 | 300-700 | 2.4 | 450 |
HG-R1100/4 | 2470X1235X1150 | 1100 | 300-900 | 3 | 520 |
HG-R1300/4 | 2470X1435X1150 | 1300 | 300-1200 | 4 | 600 |
